ZENNIO 8300020 Cable outlet mode for ZS55

The ZENNIO 8300020 product, also known as AllInBox 1612, is a multifunctional device designed for the control and monitoring of plants, integrating all the necessary functionality in only 12 DIN modules.

Key Features

This device includes a 640 mA KNX power supply, a KNX-IP interface, a climate controller with up to 4 independent thermostats, a logic module and a multifunctional actuator with 12 inputs and 16 outputs (16 A C-Load).

Power supply and interface

The 640 mA KNX power supply guarantees high stability and reliability for the entire KNX system. The KNX-IP interface allows efficient and secure communication between plant devices.

Climate Controller

The climate controller integrates up to 4 independent thermostats, offering precise and customizable temperature management in different areas of the system.

Logic Module

The logic module allows you to implement complex logics for the control and management of plants, increasing the flexibility and efficiency of the system.

Multifunctional Actuator

The multifunctional actuator has 12 inputs and 16 outputs (16 A C-Load), allowing multiple configurations such as individual outputs, curtain channels or fan coil controllers.

Possible Configurations

• Individual outputs for controlling individual devices.
• Curtain channels for managing openings.
• Fan coil controller for temperature and humidity regulation.

This device, although it has been replaced by the AllInBox 1612 v2 version, still offers all the functionality necessary for effective and efficient plant control.
