ZENNIO ZVIF2V2A ZVIF2V2A Flat 2 Backlit Capacitive Touch Keyboard, 2 Keys, Black

Key Features

This device offers a series of innovative and practical features for plant management.

• Printed glass touch panel with customizable image via web application.
• 2 configurable touch areas.
• 2 analog/digital inputs.
• Built-in thermostat.
• Internal temperature sensor with a measurement range from -30°C to +90°C and a resolution of 0.1°C.
• Brightness and proximity sensor to automatically adjust the brightness of the panel.
• Illumination of touch areas to indicate status.
• Total data storage in the event of a KNX bus failure according to the parameterization.
• Integrated KNX BCU control unit (TP1-256).

Technical Specifications

The device is designed to be compatible with the most common standards and to ensure optimal efficiency.

• Supply voltage: 29 VDC SELV (range 21-31 VDC).
• Maximum consumption: 12.2 mA @ 29 VDC (353.8 mW).
• Operating temperature: 0°C to +55°C.
• Storage temperature: -20°C to +55°C.
• Operating humidity: 5% to 95%.
• Storage humidity: 5% to 95%.
• Protection class: III.
• Type of operation: Continuous.
• Degree of protection: IP20, clean environment.
• Installation: Recessed mounting on a wall box.
• Weight: 97 g.
• Case material: PC+ABS FR V0 halogen-free.

Installation and Use

The installation of the device is relatively simple and requires a few steps.

• Secure the metal plate in the square or round wall box using the box's screws, making sure it's level.
• Connect the KNX bus and input terminals to the back of the device.
• Insert the device into its final position and verify that the force of the clips is sufficient to secure it.
