ZENNIO ZVIF2V2 ZVIF2V2 Flat 2 v2 Backlit Capacitive Touch Keyboard, 2 Keys, Custom

<p/the ZENNIO ZVIF2V2 product belongs to the family of Flat capacitive switches, characterized by a flat design and a series of innovative features.

Key Features

This device offers a tempered glass panel with capacitive touch, customizable through a web application. Versions with 1, 2, 4 or 6 touch areas are available, with the ZVIF2V2 version specifically equipped with 2 touch areas.

Glass Panel and Lighting

<p_The tempered glass panel is fully customizable with images, icons, texts or logos. The touch areas are backlit and the brightness automatically adapts to the ambient brightness thanks to the brightness and proximity sensor.

Sensors and Inputs

<p_The device includes an internal temperature sensor and a thermostat, as well as 2 analog-digital inputs configurable as binary inputs, sensors, buttons, temperature probes or motion detectors.

Technical Specifications

• Supply voltage: 29 VDC SELV (range 21-31 VDC)
• Maximum consumption: 12.2 mA @ 29 VDC (353.8 mW)
• Operating temperature: 0.. +55 °C
• Storage temperature: -20.. +55 °C
• Operating humidity: 5.. 95%
• Storage humidity: 5.. 95%
• Protection class: IP20, clean environment
• Case material: PC+ABS FR V0 halogen free
• Weight: 97 g
• Dimensions: 81 x 81 x 31 mm (protrudes 9 mm from the wall)

Installation and Compliance

<p_The device is designed to be flush-mounted on a square or round recessed box. It complies with CE, UKCA and RCM directives.

Indicators and Operating Modes

<p_The programming indicator (red LED) indicates the programming mode. The touch areas are illuminated according to their parameterization. The device saves the data in the event of a KNX bus failure and retrieves them when the bus restarts.
