ZENNIO ZVI-TMDV-G TMDV room controller, gold frame, custom

The ZENNIO ZVI-TMDV-G, known as TMD-Display View, is a KNX room controller equipped with a 1.8-inch backlit display, designed to make a desirable aesthetic impression in any environment.

Functionality

This device is able to manage various aspects of the environment, such as climate, audio, curtains and lights, thanks to its 32 functions distributed on up to 4 pages accessible by pressing or sliding on the central area of the panel.

Technical characteristics

• Typical voltage: 29.00 Volts
• Display resolution: 128 x 64 pixels
• Dimensions: 158 mm (length) x 110 mm (width) x 47 mm (height)
• Minimum ambient temperature: 5.00°C
• Maximum ambient temperature: 40.00°C
• Operating humidity: 5% - 95% RH (without condensation)
• Input type: analog/digital
• Number of inputs: 2
• Material: Aluminum
• Frame color: Aluminum, Gold, Polycarbonate, Chrome
• Color: Black, White, Custom Design
• Buttons: 8
• Bus system: KNX TP (Twisted Pair)
• Connection type: KNX bus terminal
• Protection class: IP20

Special Features

The TMD-Display View also includes a thermostatic function, an internal temperature probe and two analog/digital inputs for great functionality. The personalization is based on professional printing on high-strength tempered glass.

Practical Use

This room controller is ideal for managing various building systems in an intuitive and personalized way, thanks to its capacitive touch interface and the ability to access different functions through multiple pages.
