VIMO C1F8 Voltage distribution and disconnecting circuit

C1F8 allows you to divide and protect different power lines. Two input terminal blocks for sectioning on 8 separate lines, each protected by a fuse. The breakage of a fuse (with relative load connected) is indicated by the lighting of the corresponding LED. The circuit can be used both in direct current and in low-voltage alternating current. If used on direct current, connect clamp A to the positive pole and B to the negative pole.
