EELECTRON IN00B02RAC-8 VIRTUAL BADGE Access control module - 8 zones

EELECTRON IN00B02RAC-8 Product Description

The EELECTRON IN00B02RAC-8 module is a DIN rail device designed for home and industrial automation installations based on the KNX protocol. This module is characterized by high versatility and flexibility, making it ideal for a wide range of applications.

Key Features

The device includes:

• 8 configurable inputs to connect buttons, switches or temperature probes. 4 of these inputs can be used as analog inputs for connecting NTC temperature probes, allowing temperature measurements to be sent to the KNX bus.
• 8 relay outputs, which can be used to control loads such as lights, valves, and actuators for shutters and blinds.
• Thermostat control: the device can be configured to manage two two-stage thermostatic modules, each with an integrated PI controller for controlling heating and cooling appliances, valves and 2- and 4-pipe fan coils.
• Logic functions: it is possible to combine groups of relays (up to 8) for special functions using logic interblocks, allowing the control of complex systems such as 4-tube, 3-speed fan coils.

Configurations and Functionalities

The IN00B02RAC-8 module offers different configurations to suit various needs:

• Light and load control: the 8 relay outputs can be used to control lights, electrical loads and other devices.
• Valve and actuator control: the device supports the control of 3-point valves and solenoid actuators in PWM mode.
• Control of shutters and blinds: 4 channels are dedicated to the control of shutters and blinds.
• Scenario and sequence functions: the inputs can be used to execute scenarios, command sequences, and step-by-step commands.

Integration and Visualization

The device includes an RGB LED bar on the front side for displaying states or other quantities available on the KNX bus, facilitating system management and monitoring.

The compatibility with the main electrical box standards (Italian, German, English) and the possibility of mounting on a 2-module box make this module highly versatile and easy to integrate into any automation system.
