EELECTRON IN00B02RAC-16 VIRTUAL BADGE — HORIZONE WEBSERVER, 16 ZONES

<p/the EELECTRON IN00B02RAC-16 product is an access control module intended for access management systems in residential and commercial environments. This device is designed to manage up to 16 access zones, offering a flexible and customizable solution for specific user needs.

Technical characteristics

The IN00B02RAC-16 module is compatible with the EIB/KNX bus and can be powered through the bus cable with a voltage between 21 and 32 Vdc.

fitment

The device is designed to be mounted in standard electrical boxes: British, German or Italian with 3 modules.

Inputs

The module has configurable digital inputs for potential-free contacts (clean contacts) with a maximum cable connection length of ≤ 10 m (twisted cables).

In addition, there is a configurable rear analog input for connecting an NTC temperature probe (eelectron codes TS01A01ACC, TS01B01ACC, TS01D01ACC - not included), with a maximum cable connection length of ≤ 20 m (twisted cables).

Functionality

The IN00B02RAC-16 module allows the management of access permissions and the sending of virtual access keys through an app, both locally and remotely. This functionality also makes it ideal for unmanned facilities.

Integration with Home Automation Systems

The device is part of smart home automation solutions developed for energy savings in buildings and can be integrated with other KNX devices for a complete and centralized management of building access and functionality.

Dimensions and Design

The dimensions of the module are 96 x 126 x 36 mm, making it compatible with the main standard electrical boxes.
