KERT KAL1224502D Switching power supply with 2 separate outputs. 12Vcc (2A) - 24Vcc (1A)

Switching Technology Power (W) Output 12V (24W) - output 24V (24W) Input voltage (Vac) 100 ÷ 240 Input frequency (Hz) 50 ÷ 60 Input voltage (Vdc) 110 ÷ 350 Current with nominal output (Vin 115/230 Vac) (A) 0.45/0.50 Peak current when turned on 230 Vac (A) 35 Power factor 0.6 Fuse input protection

OUTPUT VOLTAGE (Vdc) 1 output 24Vdc

1 12Vdc output

OUTPUT CURRENT (A) 24Vdc Output: 1A

12Vdc output: 2A

Maximum battery capacity (Ah) -Intervention time (ms) 0 Parallelability outputs No Output adjustment (Vdc) 24Vdc output: 24 ÷ 28

12Vdc output: 12 ÷ 14

Hold up time (230/115 Vac) (ms) 20/5Ripple (mV rms) <10

Thermal electronic protections

Overload

Short circuit

DC OK status signals on each output

Anomaly reports Absent output voltage
