ARCUS-EDS 30801500 SK08-T8-PT500

ARCUS-EDS 30801500 - Touch_it 3.5"

The ARCUS-EDS 30801500 product, known as Touch_it 3.5", is a touch screen control panel designed for integration into the KNX automation system. This device offers a wide range of functionality for managing and controlling various aspects of home and industrial automation.

Technical characteristics

The 3.5" Touch_it is equipped with a 3.5-inch color TFT display with 320 x 240 RGB resolution and a touchscreen. The processor is a 32-Bit ARM at 1 GHz, supported by 8 GByte of flash memory. The device includes a microSD slot for SD/SDHC cards and a microUSB port.

The operating system used is Linux, and the device is equipped with an integrated infrared sensor (AC35) and a temperature sensor (PC35).

Control Features

• Lighting control and adjustment, including RGB management through direct color selection.
• Acoustic and optical alarm functions, with display of alarm states from motion sensors or switching states.
• Temperature adjustment and display, with settings for comfort, standby, economy and protection.
• Curtain and blind control.
• Management of heating and cooling systems, with temperature regulation and thermal control functions.
• Weekly schedule and astronomical clock for sun-guided events.
• Data logging and displaying diagrams.
• Creation of internal scenes with up to 32 telegrams.
• Integration of complex logical functions.

Interface and Customization

• Fully programmable via ETS5®.
• Login possible via USB.
• Six display pages with up to eight control elements each.
• Each control element can manage up to four KNX objects.
• USB tool for customizing control elements and downloading the current view page.
• Layout customizations, icons, screensavers, and more through the Touch_IT-Creator software.

Installation and Security

• Installation possible with a support ring for 60/68 mm built-in boxes, also compatible with Swiss boxes (Feller).
• Security against theft thanks to a hidden Imbus screw.

Environmental Conditions

• Storage temperature: -5°C to +60°C.
• Operating temperature: -5°C to +55°C.
• Maximum humidity: 90% non-condensing.
• Power supply: 9-32 VDC, power consumption in operation: 1.5 W, in standby: < 0.5 W.
