EELECTRON 9025GTR03L03 GLASS PLATE FOR TRANSPONDER READER 9025 BLACK

EELECTRON 9025GTR03L03 Product Description

<p The EELECTRON 9025GTR03L03 product is a KNX® thermostat/humidostat designed for precise and personalized control of temperature and humidity in residential and commercial environments.

Technical characteristics

This device is part of the EELECTRON 9025 series and has the following technical characteristics:

• Dimensions: The dimensions of the device are 96 x 126 x 36 mm, making it compatible with English, German or Italian 3-module boxes.
• Power supply: The power supply is via the EIB/KNX bus with a voltage between 21 and 32 Vdc.
• Digital Inputs: The device has digital inputs for potential-free contacts, with a maximum length of connecting cables of 10 meters (intertwined).
• Analog Input: It is possible to connect an NTC temperature probe, with specific codes such as TS01A01ACC (-20°C to +100°C), TS01B01ACC (-50°C to +60°C) and TS01D01ACC (-40°C to 125°C).

Control Features

The 9025GTR03L03 integrates a two-stage thermostat for the control of two distinct areas, both equipped with an integrated PI controller for controlling heating, cooling equipment, valves, 6-way valves and 2- and 4-pipe fan coils.

• Capacitive Bar: On the front side there is a capacitive bar with swipe function for implementing programmable KNX functions.
• RGB LED bar: The RGB LED bar is freely configurable for displaying states or other quantities available on the KNX bus.
• Logical Blocks: The device has 32 logical blocks for creating simple expressions with logical or threshold operators, or complex expressions with conditional algebraic operators.
• Virtual Pocket Logic: Integrates “Virtual Pocket Logic” to manage on/off commands, dimmers, shutters and other programmable control functions.

Configuration and Communication

The device can be configured through the ETS® application program and communicates with the KNX Data Secure protocol, ensuring secure and reliable communication within the automation system.
