EELECTRON 9025GTR03L01 GLASS PLATE FOR 9025 TRANSPONDER READER - WHITE

<p/the product EELECTRON 9025GTR03L01 is a KNX® thermostat/humidoswitch designed for precise control of temperature and humidity in residential and commercial environments.

Technical characteristics

This device is compatible with the KNX bus and can be mounted in built-in boxes of 2 or 3 modules, complying with the main standards (Italian, German, English, etc.).

Dimensions and Assembly

• Device dimensions: 96 x 126 x 36 mm
• Assembly in an English, German or Italian box of 2/3 modules

Power supply and connections

• EIB/KNX bus power supply: 21 ÷ 32 Vdc
• Digital inputs for potential-free contacts (clean contacts)
• Maximum length of connecting cables: ≤ 10 m (braided)
• Analog input for temperature probe that can be connected to NTC EELECTRON probes (for example TS01A01ACC, TS01B01ACC, TS01D01ACC)

Functionality

• 7 configurable capacitive buttons for on/off functions, dimming, shutters and other programmable command and control functions
• Two-stage thermostat for the control of two distinct areas, with integrated PI controller for controlling heating, cooling, valves and fan coils
• Capacitive bar with swipe function for implementing programmable KNX functions
• Freely configurable RGB LED bar for displaying states or other quantities available on the KNX bus
• 32 logical blocks to create logical and algebraic expressions, including proportional temperature and humidity controls and dew point calculation
• Integration of “Virtual Pocket Logic”

Conditions of Employment

• Operating temperature: -5 °C +45 °C
• Storage temperature: -20 °C +55 °C
• Relative humidity (non-condensing): max. 90%
