INIM FIRE BDH200 Linear optical reflection detector with a range of 5-70m

Linear optical reflection detector with a range of 5-70m (for a width of 15m). Complete with reflector. Automatic or manual alignment. IP65. CPR En54pt12 VdS certification. Barrier alignment and management from an App with Bluetooth connection

Linear optical smoke detector: detector with trans-reflective technology equipped with a motorized head that can align itself during start-up and continuously correct its position despite any movement of the building. Bluetooth technology allows you to carry out all the actions of the control unit through the app, but in a faster and more intuitive way. The system includes a motorized head containing an infrared transmitter/receiver and reflectors. Smoke contamination is revealed by the analysis of the infrared ray returning from the reflector with the possibility of recording a fire condition at a preliminary level. The standard system has a coverage range of up to 5 to 70m, but two additional roof extension kits are also available: from 70 to 140m using 4 reflectors, and from 140 to 160m with 9 reflectors.
