New FA100

FA100 Precision, effectiveness, versatility
The new FA100 detector represents the cutting edge in aspirating smoke detection. Featuring two independent channels and advanced technology, it offers a complete and versatile solution for fire safety.
LPCB CERTIFICATE
FA100 meets the highest safety standards and has obtained certification

TWO INDEPENDENT CHANNELS, ONE COMPLETE SYSTEM
FA100 is equipped with two independent and versatile sampling channels. Each channel is EN54-20 approved and can be configured in class A, B, or C based on specific application needs, ensuring flexibility and effectiveness

DOUBLE TECHNOLOGY, ACCURATE ANALYSIS
Dual light technology ensures accurate particle analysis. The two light sources with different wavelengths allow the size of the particulate sucked into the duct to be assessed, ensuring high rejection of false alarms caused by dust or mists.

ADVANCED SAMPLING, FOR EACH PIPE
FA100 provides measurement of air flow and temperature in each sampling tube, ensuring precise monitoring. Equipped with a two-expandable hose, it can cover up to 160m in total length and reach up to 100m distance to the farthest sampling hole.

SOFTWARE WITH 3D CAD, INTUITIVE DESIGN
FA/STUDIO, the free software with integrated 3D CAD, facilitates the design of sampling pipelines and supports the import of AUTOCAD drawings. It provides the expected regulatory limits and the technical data necessary for the calculation of the central unit parameters and includes diagnostic and reporting functions. Programming, diagnosis and reporting are also available through IP connectivity on the WiFi network integrated into the device

Integration without limits
FA100 integrates perfectly with Inim addressable fire detection systems via loop connection and with conventional systems via fully programmable relay outputs and I/O terminals.

Watch the video
