Maxinbox 16 V4 by Zennio: Advanced multifunction actuator for centralized control of KNX loads

Maxinbox 16 V4 by Zennio:

Advanced multifunction actuator for centralized control of KNX loads

In the field of residential and commercial building automation, the Maxinbox 16 V4 by Zennio stands out as a highly versatile and high-performance solution for controlling lights, shutters, valves, and other electrical loads.
Fully compliant with the KNX standard, this device ensures full interoperability and seamless integration with other certified KNX components, guaranteeing maximum design flexibility.
MT Distribuzione is an official Zennio distributor, offering immediate product availability and qualified technical support at every stage of your KNX project—from selection to installation.

What is Maxinbox 16 V4?

The Maxinbox 16 V4 is a KNX actuator equipped with 16 freely configurable relay outputs that can be used to control various electrical loads such as lighting (ON/OFF), shutters, blinds, valves, fan coils, and more.
In addition to the outputs, the device features 8 digital inputs, which can be configured for pushbuttons, sensors, or contact signals, further expanding the automation possibilities of the KNX system.

DISCOVER MAXinBOX 16 V4

Key Features

• Flexible configuration: the 16 outputs can be assigned to single channels, double channels for blinds, or grouped for fan coil control.

• Advanced shutter/blind control: complete motor management with protection against simultaneous movements and end-position adjustments.

• Fan coil support: suitable for 2- or 4-pipe systems with integrated logic for efficient HVAC control.

• Built-in thermostat function: 2 independent thermostats, which can be paired with external probes.

• 8 digital inputs: compatible with dry contacts for pushbuttons, sensors, or pulse counters.

• Configuration via ETS: the device is fully configurable using ETS software, with detailed options for every output and input.

Benefits

• High output density in a compact size (only 8 DIN modules for 16 channels).

• Reduced wiring and simplified installation.

• Full flexibility: one device to manage multiple types of loads.

• High reliability: robust relay contacts, also suitable for inductive loads.

• Scalable solution: multiple Maxinbox V4 devices can be combined for complex systems.

Applications

The Maxinbox 16 V4 is ideal for:

• Residential installations, where centralized control of lighting, shutters, and heating is needed in limited space.

• Offices and commercial spaces, thanks to support for manual controls, timing functions, and scenes.

• Hotels, schools, and public buildings, where integration with sensors and internal logic helps optimize energy consumption and efficiency.

Conclusion

The Maxinbox 16 V4 is a compact, powerful, and scalable solution for managing loads within modern KNX installations. Its combination of relay outputs, digital inputs, and logical functions makes it one of the most versatile actuators in the Zennio product range.

Available at MT Distribuzione! For technical information and personalized consultations, call us to speak directly with our KNX specialist.

The MT Distribuzione Team
