WEINZIERL 5346 MULTI IO EXTENSION SHUTTER 592

WEINZIERL 5346 Product Description

The WEINZIERL 5346 replacement relay is specifically designed for the control of curtains and shutters, and is compatible with the Multi IO Extension Shutter 592. This dual relay is connected to only one output of the KNX TP Multi IO 570 or the KNX IP Multi IO 580.

Technical characteristics

The relays are made of AgSnO2 contact material and are designed to operate with a 24 V input and a 230 V/1 A output. The delivery takes place in packs of 10 pieces.

Mechanical Data

• Plastic house
• DIN rail mounting, width: 1 module (18 mm)
• Weight: about 50 g

Indicators and Spindle

• LED (green) to indicate direction
• Glass casting 5x20mm, 6 A

Connectors

• Screw terminals (2 poles) for 24 Vinput
• Screw terminals (3-pole) for 230 Voutput

Entry and Exit

• Input voltage (signal): 24 V
• Spindle: 6 A
• Relay type: 250 V/ 6 A, bi-stable
• The switching power can be significantly reduced depending on the type of load (capacitive or inductive)

Operation

The relays are electromechanically locked against each other to prevent motor defects. The direction of the relays is automatically controlled by the KNX Multi IO through a defined interruption of the holding current.
