EELECTRON 9025GT07W03-R LINE SERIES CUSTOM GLASS - RGB - BLACK RESIDENTIAL DISPLAY

EELECTRON 9025GT07W03-R Product Description

The EELECTRON 9025GT07W03-R thermostat is a KNX® temperature controller designed to effectively and individually manage the thermal environment in various settings, including residential and hotel settings.

Key Features

This device is equipped with 7 configurable capacitive buttons, allowing the management of on/off commands, dimmers, shutters and blinds, as well as the ability to execute and learn scenarios, sequences of objects and local thermostat commands.

Thermal Control

The 9025 thermostat includes a 2-stage controller with an integrated PI controller, ideal for controlling heating and cooling appliances, valves, 2- and 4-pipe fan coils, and other equipment.

Sensors and Inputs

The device has a temperature probe on board and allows the connection of an additional NTC probe (eelectron codes TS01A01ACC or TS01B01ACC) for precise temperature measurements. A version with an integrated temperature and relative humidity sensor is also available for controlling ambient humidity.

Interface and Visualization

The RGB LED bar on the front side is freely configurable to display states or other quantities available on the KNX bus, offering a clear indication of the operating conditions of the thermostat.

Assembly and Compatibility

The device is designed to be mounted in boxes of 2 or 3 modules, compatible with the main standards (Italian, German, English, etc.).

Personalization and Functionality

The cover glasses are available in versions for residential or hotel applications and can be customized with interchangeable backlit icons, adapted to the specific needs of the user.

Logic and Programming

The 9025 thermostat can be configured using the ETS® application program and supports the KNX Data Secure protocol. It has 32 logical blocks to create complex logical and algebraic expressions, including proportional temperature and humidity controls and the calculation of the dew point.

Other Features

• Capacitive bar with swipe function for implementing programmable KNX functions.
• Integration of “Virtual Pocket Logic” to manage complex scenarios.
• Compatibility with various actuators for controlling lights, shutters, climate and other functions.
