EELECTRON IN00B02VOI KNX WEB SERVER, VOIP MODULE FOR HORIZONE WS

EELECTRON IN00B02VOI Product Description

The EELECTRON IN00B02VOI device is a two-stage thermostat designed for the control and management of environmental conditions in residential and commercial buildings, integrated into the home and building automation system based on the KNX standard.

Technical characteristics

This device has an integrated PI controller, allowing the control of heating and cooling appliances, valves, 6-way valves and 2- and 4-pipe fan coils. Its control capacity extends to two distinct areas, offering precise and customizable management of thermal conditions.

Assembly and Power Supply

• Dimensions of the device (without plate): 71x71x25 mm
• Dimensions of the 2-module frame: 92x92x11 mm
• Mounting on a built-in box (Italian, German or English with 2 modules)
• EIB/KNX bus power supply: 21 ÷ 32 V DC, max 30 mA

Sensors and Inputs

• Onboard temperature probe
• Rear input configurable as digital or analog to connect an additional NTC probe (eelectron codes TS01A01ACC, TS01B01ACC, TS01D01ACC)
• Integrated temperature and relative humidity sensor option for monitoring ambient humidity

User Interface and Functionality

• Capacitive bar with swipe function on the front side for implementing programmable KNX functions
• Freely configurable RGB LED bar for displaying states or other quantities available on the KNX bus
• 32 logical blocks for creating simple and complex expressions with logical, threshold and conditional algebraic operators
• Use of predefined algorithms for proportional temperature and humidity controls and dew point calculation
• Integration of “Virtual Pocket Logic”

Conditions of Employment

• Operating temperature: -5 °C +45 °C
• Storage temperature: -20 °C +55 °C
• Relative humidity (non-condensing): max. 90%

This device is configurable through the ETS® application program and supports the KNX Data Secure protocol, ensuring secure and reliable communication within the automation system.
