2N 9157101 IP Style Main Unit

The 2N IP Style is a high-quality video intercom, designed to meet the highest demands in terms of design, functionality and durability.

Display and User Interface

This intercom features a 10-inch touch display with a white tempered glass cover. The display is characterized by high brightness, smooth animations and a fast touch response. In addition, it features a self-disinfecting coating that eliminates 99% + of all viruses and bacteria.

Bidirectional Video Communication

The 2N IP Style supports two-way video communication, a feature that ensures clear and inclusive communication. This feature is especially useful for visitors with hearing disabilities, allowing them to communicate with reception staff through sign language.

Technical Performance

The intercom is equipped with the AXIS ARTPEC-7 processor and a full-HD camera, ensuring sharp and detailed images. In addition, it integrates WaveKey technology for secure and efficient key management.

Card Readings and Access Technologies

• Read UID (CSN) and secure MIFARE® DESFire® cards using 2N® PiCard technology.
• Reading of PACs ID (HID iClass cards with SIO object).
• Support for technologies such as ISO14443A (MIFARE® DESFire®), PicoPass (HID iClass), FeliCa, ST SR (IX) and NFC (2N® Mobile Key).

Power and Interfaces

• DC power supply: 12 V ± 15%/4 A.
• PoE+ power supply: IEEE 802.3at (Class 4—25.5 W).
• LAN interface: 10/100BASE-TX with Auto-MDIX, RJ-45.
• External Wiegand module.

Durability and Environmental Resistance

The 2N IP Style is IP65 and IK08 certified, ensuring high resistance to weather, dust and vandalism. It operates in an operating temperature range of -22°F to 140°F and relative humidity of 10% to 95% (non-condensing).

Mechanical Properties

• Weight: 4,299 lb.
• Surface mount dimensions: 6,693 (L) x 13,976 (H) x 1,575 (D) inches.
• Flush mount dimensions: 6,693 (L) x 13,976 (H) x 0.866 (D) inches.
