EELECTRON 9025GTR303L03 GLASS PLATE FOR TRANSPONDER READER 9025 BLACK

EELECTRON 9025GTR303L03 Product Description

The EELECTRON 9025GTR303L03 device is a KNX thermostat and humidifier designed for precise and customizable control of environments, particularly suitable for applications in residential and commercial buildings.

Technical characteristics

This device is available in a 3-module version, with dimensions of 96 x 126 x 36 mm, making it compatible with English, German or Italian 3-module boxes.

Power supply and connections

The power supply is via the EIB/KNX bus with a voltage between 21 and 32 Vdc. The digital connections are designed for potential-free contacts, with a maximum connection cable length of 10 meters (intertwined).

Control Features

The device integrates a two-stage thermostat for the control of two distinct areas, each with an integrated PI controller for controlling heating, cooling equipment, valves, 6-way valves and 2- and 4-pipe fan coils.

User Interface

On the front side there is a capacitive bar with swipe function for implementing programmable KNX functions. In addition, a freely configurable RGB LED bar is available for displaying states or other quantities available on the KNX bus.

Logic and Programming

The device has 32 logical blocks for creating simple expressions with logical or threshold operators, or complex expressions with conditional algebraic operators. You can use predefined algorithms such as proportional temperature and humidity controls or dew point calculation. It also integrates the “Virtual Pocket Logic”.

Configuration and Communication

The device can be configured through the ETS® application program and communicates with the KNX Data Secure protocol, ensuring high security in communications.

Sensors and Accessories

It is possible to connect the device to NTC temperature probes with specific codes (TS01A01ACC, TS01B01ACC, TS01D01ACC) and the maximum length of the connecting cables for these probes is 20 meters (intertwined).
