EELECTRON SK05A01ACC 2-MODULE DUAL ELECTA PLATE, WHITE

<p/the EELECTON SK05A01ACC product is a KNX touch panel intended for integration into home and building automation systems. This device is designed to offer complete and intuitive management of the various functionalities of the house or building.

Key Features

The SK05A01ACC touch panel has a 3.5-inch color display with customizable icons, allowing users to set temperature set points, control the color and intensity of LED lamps, and manage various usage scenarios.

Power and Connections

The device is powered via the EIB/KNX cable with a voltage between 21 and 32 V DC and a current consumption of less than 10 mA. The touch panel is equipped with a Wago connector for connecting to the KNX bus and auxiliary connectors for other functions.

Control Functionality

• Temperature management with integrated thermostat, allowing temperature regulation in different areas of the house or building.
• Control of lights, dimmers, shutters and curtains through the KNX interface.
• Management of customizable scenarios, including the hourly, daily, or weekly scheduling of household functions.
• Integration with audio systems and external devices such as TV and stereo, allowing the selection of tracks, volumes and sources.

Signals and Security

The touch panel includes an integrated buzzer for signaling alarms and front LEDs for night signaling or as a light guide. In addition, it is possible to set up password protection for device functions.

Dimensions and Assembly

The dimensions of the touch panel are 112 x 110 x 48 mm, allowing mounting in standard Italian, German or Swiss built-in boxes. The weight of the device is about 130 g.

Material and Protection Class

The touch panel case is made of polycarbonate and ABS, with a protection class II according to EN 61140.
