EELECTRON SK04A03ACC 2-MODULE ELECTA PLATE, MATT BLACK

<p The EELECTRON SK04A03ACC product is an intelligent control board from the EELECTA series, designed to integrate perfectly into domestic and commercial automation systems based on KNX.

Key Features

<p This plate is characterized by an elegant and functional design, available in a matt black finish, and is suitable for various types of built-in boxes, including standard Italian, German and Swiss ones.

Dimensions and Assembly

<p The dimensions of the plate are 112 x 110 x 48 mm, making it compatible with 2-module built-in boxes. The assembly takes place through a standard recess, ensuring a perfect integration with the surrounding environment.

Power and Connections

<p The board is powered via the EIB/KNX cable with a voltage of 21.. 32V DC and a current absorbed by the KNX bus of less than 5mA. In addition, it has Wago connectors for connecting to the EIB/KNX bus and for auxiliary connections.

Functionality

<p The EELECTRON SK04A03ACC plate is equipped with a 3.5-inch color display, fully programmable to manage various functions such as lighting, dimmers, RGB lights, shutters and timers. It also includes an integrated temperature sensor for controlling valves, fan coils and other thermoregulation systems.

Control Logics

<p The device includes pre-programmed logic for controlling electrical loads with automatic shutdown based on priority, a functionality available in association with the eElectron KNX power meter device.

Indicators and Signals

<p The plate has LEDs for displaying the status and a buzzer for sound signals and alarm functions, ensuring effective communication with the user.

Configuration and Scheduling

<p The plate is programmed exclusively through ETS (Engineering Tool Software), without the need for additional software. Each front LED is freely configurable via ETS.

Security and Protection

<p The plate has a protection class II according to EN 61140 and a case made of polycarbonate and ABS, ensuring high strength and safety.
