WP RACK WPC-FTH-PLC4SCA Fiber Optical PLC Splitter Singlemode G657A1 SC/APC 1 to 4

PLC (Planar Lightwave Circuit Splitter) optical splitters are passive devices used to divide a beam of light into multiple beams uniformly. The PLC optical splitter provides a low-cost passive signal distribution solution with high stability and reliability. Optical splitters can offer a split ratio of up to 1x64 and are indispensable in PON networks (EPON, GPON, FTTX).

Specifications:

1x4 PLC Splitter.

Operating Wavelength (NM): 1260~1650

Fiber type: G657.A1

Insertion Loss (DB): 7.1

Loss uniformity (DB): 0.6

Bias Dependent Loss (DB): 0.2

Return loss (DB) (P/S grade): 55/50

Directivity (DB): 55

Wavelength dependent loss (DB): 0.3

Splitter size (mm): 40x4x4

Input cable length: 1MT.

Output cable length: 1MT.
