EELECTRON PO71A71FX-0724 2X71 FENIX GREY 0724 DOUBLE PLATE

EELECTRON PO71A71FX-0724 Product Description

The EELECTRON PO71A71FX-0724 device, part of the OL-U® KNX® series, is a multifunctional humidifier and thermostat designed for wall installation and characterized by Fenix finishes for the buttons and plates.

Key Features

This device integrates temperature and humidity sensors, ensuring precise management of environmental conditions. It includes two two-stage thermostats for controlling two distinct areas, both equipped with an integrated PI controller for controlling heating, cooling equipment, valves, 6-way valves and 2- and 4-pipe fan coils.

Sensors and Controls

The humidity sensor manages the reading of the relative humidity of the environment and allows the threshold control with hysteresis of humidification and dehumidification devices. The device is also equipped with an LCD display with adjustable backlighting, making it easy to view information in any light condition.

Interface and Commands

On the front side of the device there is a capacitive bar with swipe function for implementing programmable KNX functions. In addition, 4 mechanical keys (8 channels) are available for managing on/off commands, dimmers, shutters and blinds, or other programmable command and control functions.

Visualization and Logic

A freely configurable RGB LED bar is available for displaying states or other quantities available on the KNX bus. The device has 32 logical blocks with which to create simple expressions with logical or threshold operators, or complex expressions with conditional algebraic operators. You can use predefined algorithms such as proportional temperature and humidity controls or dew point calculation.

Integration and Security

The device is configurable through the ETS® application program and can communicate with the KNX Data Secure protocol, ensuring secure and reliable communication within the KNX network. It also integrates the “Virtual Pocket Logic” to manage complex control logics.

Presence Detection

The presence detection solution, particularly useful in environments such as hotel rooms, uses a magnetic sensor installed on the door and connected to a digital input to manage accurate presence information. The system can infer the presence of people in the room using one or more dedicated sensors and also detects accidental presences, differentiating multiple behaviors.

Compatibility and Installation

The device is available in various colors and can be installed on boxes of 2 or 3 modules, ensuring compatibility with the main standards (Italian, German, English, Swiss).
