EELECTRON BK04MT-CH KIT 4 SQUARE BUTTONS METAL CHAMPAGNE - LINE

EELECTRON BK04MT-CH Product Description

The KNX EELECTRON BK04MT-CH universal dimmer is a versatile and highly configurable device, designed to control different types of lighting loads. This 4-channel dimmer can be used independently or combined in pairs (1+2 and 3+4) to manage higher power loads, always in compliance with the maximum power values indicated.

Key Features

• Automatic identification of the type of load and adjustable parameters to optimize the control of LED, incandescent, halogen lamps, dimmable compact fluorescent lamps (CFL) and low voltage lamps with electronic or ferromagnetic transformers.
• Each output channel can be configured in two load regulation modes:
  • Trailing Edge [RC]: The dimmer reduces the final part of the input voltage wave, resulting in a reduction in lamp output. This load regulation is used for resistive or capacitive loads (typically halogen lamps with electronic transformer or incandescent lamps).
  • Leading Edge [L]: The dimmer reduces the initial part of the input voltage wave, resulting in a reduction in lamp output. This load regulation is used for inductive loads (typically ferromagnetic or toroidal transformers).
• Use the DimmerLoadTester software to analyze the peak absorption of a single lamp and calculate the maximum number of lamps that can be connected.

Configuration and Use

The configuration of the output channels can be carried out through the ETS software, allowing a detailed customization of the settings to adapt to different lighting needs.

Applications

• Lighting control in residential and commercial environments.
• Management of variable power loads with the possibility of combining channels for higher loads.
• Integration with other KNX devices for a complete and integrated management of lighting and other control systems.
