TZ15-W-V4 DIVUS TOUCHZONE 15 WHITE - touch panel for buildings

<p_The DIVUS TZ15-W-V4 is a recessed touch panel for buildings, designed for display purposes. This device features a 15.6-inch (39.6 cm) multitouch display with capacitive screen technology and ultra clear glass.

Technical characteristics

The panel is based on an ultra compact design with an embedded wall-mount PC, operating with the Android operating system.

Operating System and Hardware

The DIVUS TZ15-W-V4 uses the Android 9 operating system and has 4 GB of RAM and 16 GB of eMMC flash memory.

Interface and Connectivity

This panel includes several connectivity options, including:

• 1 x Ethernet over RJ45 with IEEE Std 802.3at™ support
• Optional: WiFi 802.11 a/b/g/n and Bluetooth 4.0 LE
• 2 x USB 2.0 and 1 x mini USB OTG
• Optional: RS-232/422/485 serial interface
• GPIO - 4 x inputs/4 x outputs for 4 relays with a maximum of 100 mA/5VDC

Sensors and Multimedia

The panel is equipped with:

• Proximity sensor and light sensor
• G-sensor for automatic display orientation in portrait or landscape mode
• Built-in 2 Watt RMS speaker and microphone with echo cancellation for two-way communication

Environmental Conditions

The DIVUS TZ15-W-V4 is designed to operate under specific environmental conditions:

• Temperature: from 0°C to 30°C
• Relative humidity: according to the indicated EMC and safety specifications (IEC 63044-1:2017, IEC 63044- 5-1:2019, etc.)

Other Features

The panel has no moving parts, ensuring quiet operation and low energy consumption (maximum 9 W without peripherals). The glass surface is smooth and homogeneous, with an aluminum edge.
