EELECTRON CS10A01KNX-1-3M CAPACITIVE PUSH-BUTTON PANEL WITH UP TO 10 BUTTONS - WHITE

The KNX® EELECTRON CS10A01KNX-1-3M capacitive button is a versatile and highly configurable device, designed to meet the needs of domestic and industrial automation.

Key Features

This button is part of the KNX® 9025 series and is available in 4, 8 or 10 channel versions. Each button can be configured to manage a variety of commands, including on/off, dimmers, control of shutters and blinds, execution and learning of scenarios, and sequences of objects.

Temperature Control

The device includes a 2-stage thermostat with an integrated PI controller, allowing the control of heating and cooling appliances, valves, and 2- and 4-pipe fan coils. It is equipped with an on-board temperature probe and has an input on the back side that can be configured as digital or analog. It is possible to connect an additional NTC probe (eelectron codes TS01A01ACC or TS01B01ACC) to obtain a second temperature measurement.

Visualization and Personalization

The KNX® 9025 series includes an RGB LED bar on the front side for displaying states or other quantities available on the KNX bus. The glass covers are available in two ranges: STANDARD and RGB, with the possibility of customizing the glasses in the CUSTOM version. The CUSTOM version glasses can backlight personalized and interchangeable icons associated with the configured functions.

Assembly and Power Supply

The device can be installed on 2 or 3-module built-in boxes and is compatible with the main standards (Italian, German, English, etc.). The power supply is via EIB/KNX bus with a voltage of 21 ÷ 32 Vdc and a maximum consumption of 30 mA.

Conditions of Employment

The button operates in the temperature range from -5 °C to +45 °C and can be stored between -20 °C and +55 °C. The maximum allowed relative humidity is 90% (non-condensing).

Dimensions and Assembly

• Device dimensions (without plate): 71x71x25 mm
• 2-module frame dimensions: 92x92x11 mm
• 3-module frame dimensions: 130x92x11 mm

Additional Features

The device has 32 logical blocks for creating simple expressions with logical or threshold operators. The capacitive bar on the front side allows the implementation of programmable KNX functions through the swipe function.
