ELSNER 70812 Cala Touch KNX TH 3.x- jet black RAL 9005 Environmental controller with temperature/humidity sensor

The ELSNER 70812 Cala Touch KNX environment controller is a versatile and highly integrated device, designed to manage various aspects of climate and lighting in residential and commercial environments.

Key Features

This device is equipped with a color touch display with a diagonal of 2.3 inches and a resolution of 320 x 240 pixels. Its structure is made of real glass and plastic, available in two colors: black (RAL 9005) and white (RAL 9010).

Installation and Protection

The installation takes place by recessed mounting in a Ø 60 mm junction box, with a mounting depth of about 7 mm. The device has an IP20 protection rating and dimensions of 55 mm x 55 mm x 35 mm.

Control Functionality

• Temperature control, with the possibility of changing the mode (heating/cooling) and indication of the current state.
• Operation of 3 drives for curtains and windows, with buttons, sliders and position display (including the position of the slats).
• Lighting control, with the possibility of turning on, turning off and adjusting the light intensity (with percentage display).
• Control of the RGB light and the color temperature of the light.
• Human-centric lighting control (HCL), with adaptation of the color temperature of the light over adjustable periods of time.
• Management of up to 4 scenes, with recall, storage and status indication.
• Weekly timer with 8 time periods.

Integrated sensors

The device includes integrated sensors for measuring temperature and humidity. The temperature can be measured with a range from -20°C to +70°C, while the relative humidity can be measured between 0% and 100% RH.

Other Features

• Display pages for current measured values and bus data (4 universal spaces).
• Information pages that display up to 2 text objects each.
• Device settings, including the ability to activate or deactivate the key tone and screen saver (clock, alternating internal/external temperature, off).
• 4 inputs for binary contacts or T-NTC temperature sensors.
• 8 AND logic gates and 8 OR logic gates, each with 4 inputs.
• 8 multifunctional modules to modify input data through calculations, condition queries or data point type conversion.

Environmental Conditions

The device can operate in a temperature range from 0°C to +45°C and in a non-condensing relative humidity between 5% and 95% RH. The storage temperature ranges from -25°C to +70°C.
